Insert Boxes

IB


Carbide Insert Compartment Packaging
Insert Boxes

IB–Product Media

Ceramic Inserts Compartment Packaging Plastic Sliding Lid Tackle Boxes Sliding Lid Compartment Boxes Compartment Box Packaging Carbide Insert Packaging Carbide Insert Compartment Packaging Carbide Insert Compartment Boxes
  • Material: PP (Polypropylene)
  • Features Individual Compartments
  • Simple Sliding Lid Opens in Either Direction
  • Locks Together When Stacking
  • Suitable for packaging items for vending machine sales
  • Available in a Wide Variety of Sizes, Styles and Cell Counts

Available in the following varieties:

IBM - Insert Boxes (Moulded Partitions) Insert Boxes with Plastic Dividers
IBF - Insert Boxes (Foam Partitions) Insert Boxes with Foam Dividers

Videos - Plastic Sliding Lid Tackle Boxes

Size Chart Sliding Lid Compartment Boxes

IB Size Chart

Table View
List View
Reference # Description Image Cell Count Foam
Cells		 Inside Length
mm
in
 Inside Width
mm
in
 Inside Height
mm
in
 Outside Length
mm
in
 Outside Width
mm
in
 Outside Height
mm
in
 Box/Mini/Micro
QTY		 Buy Online
IB10/M1 Insert Boxes - 31/64X31/64X1/4 (12.0 X12.0X6.6 MM) 10 CELL INSERT BOX IB10/M1 10
12.0
0.472
12.0
0.472
6.6
0.260
67.0
2.638
27.5
1.083
12.4
0.488
 500 100 10
IB01/M1KF42 Packaging for Carbide Inserts - 5/8X5/8X9/32" (16X16X7MM) 1 FOAM CELL INSERT BOX IB01/M1KF42 1 ✓
16.0
0.630
16.0
0.630
7.0
0.276
67.0
2.638
27.5
1.083
15.8
0.622
 500 100 10
IB02/M1 Boxes for Carbide Inserts - 1.24X.98X.60 (31.40 x 24.9 x 15.2 MM) 2 CELL INSERT BOX IB02/M1 2
31.4
1.236
24.9
0.980
15.2
0.598
67.0
2.638
27.5
1.083
21.0
0.827
 500 100 10
IB01/M1 Carbide Insert Compartment Boxes - 2.51X.98X.39 (63.8 x 24.9 x 10.0 MM) 1 CELL INSERT BOX IB01/M1 1
63.8
2.512
24.9
0.980
10.0
0.394
67.0
2.638
27.5
1.083
15.8
0.622
 500 100 10
IB02/M2 Carbide Insert Compartment Packaging - 2.51X.47X.60 (63.8 x 11.9 x 15.2 MM) 2 CELL INSERT BOX IB02/M2 2
63.8
2.512
11.9
0.469
15.2
0.598
67.0
2.638
27.5
1.083
21.0
0.827
 500 100 10
IB01/A1KF29 Carbide Insert Packaging - 1/2X1/2X5/32" (13X13X4MM) 10 FOAM CELL BOX IB01/A1KF29 10 ✓
13.0
0.512
13.0
0.512
4.0
0.157
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB01/A1KF27 Compartment Box Packaging - 5/8X5/8X5/32" (16X16X4MM) 1 FOAM CELL BOX IB01/A1KF27 1 ✓
16.0
0.630
16.0
0.630
4.0
0.157
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB01/A1KF30 Sliding Lid Compartment Boxes - 43/64X33/64X5/32" (17X13X4MM) 10 FOAM CELL BOX IB01/A1KF30 10 ✓
17.0
0.669
13.0
0.512
4.0
0.157
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB01/A1KF32 Plastic Sliding Lid Tackle Boxes - 43/64X33/64X5/32" (17X13X4MM) 6 FOAM CELL BOX IB01/A1KF32 6 ✓
17.0
0.669
13.0
0.512
4.0
0.157
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB05/A1 Insert Boxes - .72X.72X.26 (18.3 x 18.3 x 6.6 MM) 5 CELL INSERT BOX IB05/A1 5
18.3
0.720
18.3
0.720
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB10/A1 Packaging for Carbide Inserts - 23/32X23/32X1/4 (18.3X18.3X6.6 MM) 10 CELL INSERT BOX IB10/A1 10
18.3
0.720
18.3
0.720
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB01/A1KF31 Boxes for Carbide Inserts - 1-3/16X19/32X5/32" (30X15X4MM) 5 FOAM CELL BOX IB01/A1KF31 5 ✓
30.0
1.181
15.0
0.591
4.0
0.157
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB02/A1 Carbide Insert Compartment Boxes - 1.86X1.48X.26 (47.15 x 37.5 x 6.6 MM) 2 CELL INSERT BOX IB02/A1 2
47.2
1.856
37.5
1.476
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB01/A1KF28 Carbide Insert Compartment Packaging - 3-25/64X1-1/16X5/32" (86X27X4MM) 1 FOAM CELL BOX IB01/A1KF28 1 ✓
86.0
3.386
27.0
1.063
4.0
0.157
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB01/A1 Carbide Insert Packaging - 3-3/4X1-15/32X1/4 (95.3X37.5X6.6 MM) 1 CELL INSERT BOX IB01/A1 1
95.3
3.752
37.5
1.476
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB10/A2 Compartment Box Packaging - .47X.47X.26 (12.0 x 12.0 x 6.6 MM) 10 CELL INSERT BOX IB10/A2 10
12.0
0.472
12.0
0.472
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB05/A2 Sliding Lid Compartment Boxes - 1-13/64X61/64X1/4 (30.5X24.4X6.6 MM) 5 CELL INSERT BOX IB05/A2 5
31.1
1.224
24.4
0.961
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB02/A2 Plastic Sliding Lid Tackle Boxes - 1.86X1.48X.39 (47.15 x 37.5 x 10.0 MM) 2 CELL INSERT BOX IB02/A2 2
47.2
1.856
37.5
1.476
10.0
0.394
97.7
3.846
40.4
1.591
15.8
0.622
 500 100 10
IB10/A3 Insert Boxes - .35X1.48X.32 (8.8 x 37.5 x 8.2 MM) 10 CELL INSERT BOX IB10/A3 10
8.8
0.346
37.5
1.476
8.2
0.323
97.7
3.846
40.4
1.591
14.0
0.551
 500 100 10
IB10/A4 Packaging for Carbide Inserts - 23/32X45/64X25/64 (18.4X18.4X10.0 MM) 10 CELL INSERT BOX IB10/A4 10
18.3
0.720
18.3
0.720
10.0
0.394
97.7
3.846
40.4
1.591
15.8
0.622
 500 100 10
IB10/A5 Boxes for Carbide Inserts - .57X1.02X.26 (14.4 x 25.8 x 6.6 MM) 10 CELL INSERT BOX IB10/A5 10
14.4
0.567
25.8
1.016
6.6
0.260
97.7
3.846
40.4
1.591
12.4
0.488
 500 100 10
IB08/B1 Carbide Insert Compartment Boxes - .63X2.09X.75 (15.9 x 53.0 x 19.0 MM) 8 CELL INSERT BOX IB08/B1 8
15.9
0.626
53.0
2.087
19.0
0.748
137.9
5.429
56.4
2.220
25.4
1.000
 250 50 5
IB01/B1KF33 Carbide Insert Compartment Packaging - 3/4X3/4X13/64" (19X19X5MM) 10 FOAM CELL BOX IB01/B1KF33 10 ✓
19.0
0.748
19.0
0.748
5.0
0.197
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB01/B1KF34 Carbide Insert Packaging - 3/4X3/4X13/64" (19X19X5MM) 5 FOAM CELL BOX IB01/B1KF34 5 ✓
19.0
0.748
19.0
0.748
5.0
0.197
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB01/B1KF35 Compartment Box Packaging - 29/32X3/4X13/64" (23X19X5MM) 10 FOAM CELL BOX IB01/B1KF35 10 ✓
23.0
0.906
19.0
0.748
5.0
0.197
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB05/B1 Sliding Lid Compartment Boxes - 1-1/64X1-1/64X21/64 (26.0X26.0X8.2 MM) 5 CELL INSERT BOX IB05/B1 5
26.0
1.024
26.0
1.024
8.2
0.323
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB10/B1 Plastic Sliding Lid Tackle Boxes - 1-1/64X1-1/64X21/64 (26.0X26.0X8.2 MM) 10 CELL INSERT BOX IB10/B1 10
26.0
1.024
26.0
1.024
8.2
0.323
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB01/B1KF36 Insert Boxes - 1-3/8X25/64X13/64" (35X10X5MM) 5 FOAM CELL BOX IB01/B1KF36 5 ✓
35.0
1.378
10.0
0.394
5.0
0.197
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB01/B1KF37 Packaging for Carbide Inserts - 1-3/8X29/32X13/64" (35X23X5MM) 5 FOAM CELL BOX IB01/B1KF37 5 ✓
35.0
1.378
23.0
0.906
5.0
0.197
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB01/B1KF38 Boxes for Carbide Inserts - 1-49/64X25/64X13/64" (45X10X5MM) 10 FOAM CELL BOX IB01/B1KF38 10 ✓
45.0
1.772
10.0
0.394
5.0
0.197
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB02/B1 Carbide Insert Compartment Boxes - 2.62X2.09X.50 (66.5 x 53.0 x 12.8 MM) 2 CELL INSERT BOX IB02/B1 2
66.5
2.618
53.0
2.087
12.8
0.504
137.9
5.429
56.4
2.220
19.2
0.756
 500 100 10
IB01/B1 Carbide Insert Compartment Packaging - 5-9/32X2-5/64X35/64 (134.0X53.0X8.2 MM) 1 CELL INSERT BOX IB01/B1 1
134.0
5.276
53.0
2.087
8.2
0.323
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB05/B2 Carbide Insert Packaging - 1.02X1.02X.50 (26.0 x 26.0 x 12.8 MM) 5 CELL INSERT BOX IB05/B2 5
26.0
1.024
26.0
1.024
12.8
0.504
137.9
5.429
56.4
2.220
19.2
0.756
 500 100 10
IB10/B2 Compartment Box Packaging - 1.02X1.02X.75 (26.0 x 26.0 x 19.0 MM) 10 CELL INSERT BOX IB10/B2 10
26.0
1.024
26.0
1.024
19.0
0.748
137.9
5.429
56.4
2.220
25.4
1.000
 250 50 5
IB02/B2 Sliding Lid Compartment Boxes - 2.62X2.09X.50 (66.5x53.0x12.8 MM) 2 CELL INSERT BOX W/POST IB02/B2 2
66.5
2.618
53.0
2.087
12.8
0.504
137.9
5.429
56.4
2.220
19.2
0.756
 500 100 10
IB05/B3 Plastic Sliding Lid Tackle Boxes - 1.02X2.09X.32 (26.0 x 53.0 x 8.2 MM) 5 CELL INSERT BOX IB05/B3 5
26.0
1.024
53.0
2.087
8.2
0.323
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB10/B3 Insert Boxes - 1-1/32X1-1/32X35/64 (26.2X26.2X14. MM) 10 CELL INSERT BOX IB10/B3 10
26.2
1.032
26.2
1.032
14.0
0.551
137.9
5.429
56.4
2.220
20.4
0.803
 500 100 10
IB10/B4 Packaging for Carbide Inserts - 1.02X1.02X1.02 (26.0 x 26.0 x 26.0 MM) 10 CELL INSERT BOX IB10/B4 10
26.0
1.024
26.0
1.024
26.0
1.024
137.9
5.429
56.4
2.220
32.4
1.276
 250 50 5
IB05/B4 Boxes for Carbide Inserts - 1.02X2.09X.50 (26.0 x 53.0 x 12.8 MM) 5 CELL INSERT BOX IB05/B4 5
26.0
1.024
53.0
2.087
12.8
0.504
137.9
5.429
56.4
2.220
19.2
0.756
 500 100 10
IB05/B5 Carbide Insert Compartment Boxes - 1-1/64X2-5/64X35/64 (26.0X53.0X14.0 MM) 5 CELL INSERT BOX IB05/B5 5
26.0
1.024
53.0
2.087
14.0
0.551
137.9
5.429
56.4
2.220
20.4
0.803
 500 100 10
IB05/B6 Carbide Insert Compartment Packaging - 1.02X2.09X.75 (26.0 x 53.0 x 19.0 MM) 5 CELL INSERT BOX IB05/B6 5
26.0
1.024
53.0
2.087
19.0
0.748
137.9
5.429
56.4
2.220
25.4
1.000
 250 50 5
IB05/B7 Carbide Insert Packaging - 1.74X1.46X.32 (44.3 x 37.1 x 8.2 MM) 5 CELL INSERT BOX IB05/B7 5
44.3
1.744
37.1
1.461
8.2
0.323
137.9
5.429
56.4
2.220
14.6
0.575
 500 100 10
IB10/C1 Compartment Box Packaging - 45/64X1-13/64X17/32 (17.8X30.5X13.5 MM) 10 CELL INSERT BOX IB10/C1 10
17.8
0.701
30.5
1.201
13.5
0.532
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB01/C1KF41 Sliding Lid Compartment Boxes - 3/4X3/4X7/16" (19X19X11MM) 5 FOAM CELL BOX IB01/C1KF41 5 ✓
19.0
0.748
19.0
0.748
11.0
0.433
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB01/C1KF40 Plastic Sliding Lid Tackle Boxes - 29/32X25/32X7/16" (23X20X11MM) 2 FOAM CELL BOX IB01/C1KF40 2 ✓
23.0
0.906
20.0
0.787
11.0
0.433
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB05/C1 Insert Boxes - 1-13/64X1-13/64X17/32 (30.5X30.5X13.5 MM) 5 CELL INSERT BOX IB05/C1 5
30.5
1.201
30.5
1.201
13.5
0.532
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB01/C1KF39 Packaging for Carbide Inserts - 1-1/2X29/32X7/16" (38X23X11MM) 1 FOAM CELL BOX IB01/C1KF39 1 ✓
38.0
1.496
23.0
0.906
11.0
0.433
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB01/C1 Boxes for Carbide Inserts - 3-45/64X2-29/64X17/32 (93.7X62.0X13.5 MM) 1 CELL INSERT BOX IB01/C1 1
93.8
3.693
62.2
2.449
13.5
0.532
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB05/C2 Carbide Insert Compartment Boxes - 45/64X2-29/64X17/32 (17.8X62.2X13.5 MM) 5 CELL INSERT BOX IB05/C2 5
17.8
0.701
62.2
2.449
13.5
0.532
97.0
3.819
66.0
2.598
19.9
0.783
 500 100 10
IB05/D1 Carbide Insert Compartment Packaging - 1-13/32X1-13/32X17/32 (35.8X35.8X13.5 MM) 5 CELL INSERT BOX IB05/D1 5
35.8
1.409
35.8
1.409
13.5
0.532
114.5
4.508
76.0
2.992
19.9
0.783
 250 50 5
IB06/D1 Carbide Insert Packaging - 1.41X1.41X.98 (35.8 x 35.8 x 25.0 MM) 6 CELL INSERT BOX IB06/D1 6
35.8
1.409
35.8
1.409
25.0
0.984
114.5
4.508
76.0
2.992
31.4
1.236
 250 50 5
IB01/D1 Compartment Box Packaging - 4.32X2.87X.59 (109.8 x 72.8 x 15.0 MM) 1 CELL INSERT BOX IB01/D1 1
109.8
4.323
72.8
2.866
15.0
0.591
114.5
4.508
76.0
2.992
21.4
0.843
 250 50 5
IB05/D2 Sliding Lid Compartment Boxes - 1.41X1.41X.41 (35.8 x 35.8 x 10.5 MM) 5 CELL INSERT BOX IB05/D2 5
35.8
1.409
35.8
1.409
10.5
0.413
114.5
4.508
76.0
2.992
16.9
0.665
 250 50 5
IB05/D3 Plastic Sliding Lid Tackle Boxes - 1.41X1.41X.98 (35.8 x 35.8 x 25.0 MM) 5 CELL INSERT BOX IB05/D3 5
35.8
1.409
35.8
1.409
25.0
0.984
114.5
4.508
76.0
2.992
31.4
1.236
 250 50 5
IB05/D4 Insert Boxes - .83X1.56X.59 (21.0 x 39.5 x 15.0 MM) 5 CELL INSERT BOX IB05/D4 5
21.0
0.827
39.5
1.555
15.0
0.591
114.5
4.508
76.0
2.992
21.4
0.843
 250 50 5
Reference # Description Image Cell Count Foam
Cells		 Inside Length
mm
in
 Inside Width
mm
in
 Inside Height
mm
in
 Outside Length
mm
in
 Outside Width
mm
in
 Outside Height
mm
in
 Box/Mini/Micro
QTY		 Buy Online
Legend:
- Add to Basket - Buy now - View Price


message
Warning message embossed on bottom of all items.
Click image to zoom
message
Custom Logos available. Contact us for more information.




Insert Boxes - Information

Insert Boxes are the ideal packaging solution for high quality carbide blade inserts as well as any small delicate set of items that require individual compartmental storage.

Transparent lid offers secure centre locking position with quick, simple sliding opening/closing in either direction. Optional custom cut foam inserts are available to provide extra protection for ceramic, diamond and delicate inserts. The Insert Boxes conveniently lock together when stacked and are re-useable.

Insert Boxes are handy packaging options for industries such as fishing, hunting, hobby, craft, hardware, office supplies, medical, dental and many more.

Our Insert Boxes are available in natural or coloured Polypropylene (PP) and is 100% recyclable. Custom colours available.

This product can be used to package a wide variety of tooling inserts:
  • Tungsten Carbide Inserts
  • Ceramic Inserts
  • Diamond tools
  • Grooving Inserts
  • HSS Inserts
  • Indexable milling inserts
  • ISO turning inserts
  • Lancing inserts
  • Multi-tooth inserts
  • Parting Inserts
  • Thread milling cutters
  • Thread milling inserts
  • Thread turning inserts


Contact Cleartec Packaging for more information.



RoHS




Customer Service


Cleartec Packaging
A Division of MOCAP Ltd.
Hortonwood 35
Telford
Shropshire, G.B.
TF1 7YW

0800 046 7436

Diagram
Cleartec Packaging - Insert Boxes
© 2024 MOCAP. All Rights Reserved.
