Insert Boxes - Snap Pak

IBSP


Diamond tools Compartment Boxes
Insert Boxes - Snap Pak

IBSP–Product Media

Lancing inserts Compartment Packaging Boxes for Indexable milling inserts Compartmental Packaging for Parting Inserts HSS Inserts Packaging Multi-compartment packaging for Grooving Inserts Diamond tools Compartment Boxes Boxes for Ceramic Inserts Detachable Packaging for Carbide Inserts Insert Box Snap Pak's
  • Material: ABS (Acrylonitrile butadiene styrene)
  • Stocked Material: LDPE (Mid Grey)
  • Simple Sliding Lid Opens in Either Direction
  • Featuring Five Connected Units That Can Be Individually Detached
  • Excellent for Stacking and Storing
  • Suitable for packaging items for vending machine sales
  • Available in Various Multi-Compartment Configurations

Size Chart Compartmental Packaging for Parting Inserts

IBSP Size Chart

Table View
List View
Reference # Description Image Cell Count # of Detachable Units Inside Length
mm
in
Inside Width
mm
in
Inside Height
mm
in
Outside Length
mm
in
Outside Width
mm
in
Outside Height
mm
in
Box/Mini/Micro
QTY
Buy Online
IBSP05/E Insert Boxes - Snap Pak - .71X1.46X.33 (18 X 37 X 8.5 MM) 5 CELL INSERT BOX SNAP PAK IBSP05/E 5 5
37.0
1.457
18.0
0.709
8.5
0.335
133.2
5.244
40.2
1.583
12.4
0.488
500 100 10
IBSP10/EL Insert Box Snap Pak's - .33X1.46X.33 (8.5 X 37 X 8.5 MM) 10 CELL INSERT BOX SNAP PAK IBSP10/EL 10 5
37.0
1.457
8.5
0.335
8.5
0.335
133.2
5.244
40.2
1.583
12.4
0.488
500 100 10
IBSP10/EW Detachable Packaging for Carbide Inserts - .71X.71X.33 (18 X 18 X 8.5 MM) 10 CELL INSERT BOX SNAP PAK IBSP10/EW 10 5
18.0
0.709
18.0
0.709
8.5
0.335
133.2
5.244
40.2
1.583
12.4
0.488
500 100 10
IBSP10/EWP Boxes for Ceramic Inserts - .71X.71X.33 (18 X 18 X 8.5 MM) 10 CELL INSERT BOX SNAP PAK IBSP10/EWP 10 5
18.0
0.709
18.0
0.709
8.5
0.335
133.2
5.244
40.2
1.583
12.4
0.488
500 100 10
IBSP05/F Diamond tools Compartment Boxes - 1.20X2.44X.51 (30.5 X 62 X 13 MM) 5 CELL INSERT BOX SNAP PAK IBSP05/F 5 5
62.0
2.441
30.5
1.201
13.0
0.512
198.1
7.799
65.5
2.579
16.9
0.665
250 50 5
IBSP10/FL Multi-compartment packaging for Grooving Inserts - .58X2.44X.51 (14.7 X 62 X 13 MM) 10 CELL INSERT BOX SNAP PAK IBSP10/FL 10 5
62.0
2.441
14.7
0.579
13.0
0.512
198.1
7.799
65.5
2.579
16.9
0.665
250 50 5
IBSP10/FW HSS Inserts Packaging - 1.20X1.20X.51(30.5X30.5X13 MM) 10 CELL INSERT BOX SNAP PAK IBSP10/FW 10 5
30.5
1.201
30.5
1.201
13.0
0.512
198.1
7.799
65.5
2.579
16.9
0.665
250 50 5
IBSP10/FWP Compartmental Packaging for Parting Inserts - 1.20X1.20X.51(30.5X30.5X13 MM) 10 CELL INSERT BOX SNAP PAK IBSP10/FWP 10 5
30.5
1.201
30.5
1.201
13.0
0.512
198.1
7.799
65.5
2.579
16.9
0.665
250 50 5
Reference # Description Image Cell Count # of Detachable Units Inside Length
mm
in
Inside Width
mm
in
Inside Height
mm
in
Outside Length
mm
in
Outside Width
mm
in
Outside Height
mm
in
Box/Mini/Micro
QTY
Buy Online
Legend:
- Add to Basket - Buy now - View Price





Insert Boxes - Snap Pak - Information

Insert Box Snap Paks are the ideal packaging solution for high quality carbide blade inserts as well as any small delicate set of items that require individual compartmental storage. Each 'Pak' is made up of 5 individual detachable units, perfect for both multiple and single item packaging.

Transparent lid offers secure center locking position with quick, simple sliding opening/closing in either direction. The Insert Box Snap Paks conveniently stack together and are re-useable.

Our Insert Box Snap Paks are stocked in Gray ABS material with Clear ABS lid. Custom colors available.


This product can be used to package a wide variety of tooling inserts:
  • Tungsten Carbide Inserts
  • Ceramic Inserts
  • Diamond tools
  • Grooving Inserts
  • HSS Inserts
  • Indexable milling inserts
  • ISO turning inserts
  • Lancing inserts
  • Multi-tooth inserts
  • Parting Inserts
  • Thread milling cutters
  • Thread milling inserts
  • Thread turning inserts


Contact Cleartec Packaging for more information.
